Гидронасос Casappa 03580925

Гидронасос Casappa 03580925

KP3038D0-A9P1-LGF

KP30.38D0-A9P1-LGF /GC/GE/W-N-

MERLO 32.7

Number of pump elements: 1

Type Flange: Type N

Total length pump L1 (mm): 331

Neck diameter D2 (mm): 95

Axis type: Type G

Distance end — flange L2 (mm): 52

Groove width or slot W (mm): 5

Thread (on axis) TA2: M16

Direction of rotation: clockwise

Position suction 1, only for pump type T POS-CO1: Side

Connection type suction inlet 1, only for pump type T: Type E

Thread type suction element 1 TA-Pa: 1 BSP

Flow divider available: YES

Thread type largest Flow divider connection TA3: 3/4 BSP

Thread type 2nd connection from flow divider TA4: 3/8 BSP

Housing material: metal
